American Wire Gauge:
22 AWG
Current Rating:
4 A
Number of Cores:
4
Connector 2 Housing Gender:
Female
Outer Diameter:
4.7mm
Sheath Material:
PP
Cable Shape:
Twisted Pair
IP Rating:
IP65, IP67, IP68, IP69K
Voltage Rating:
250 V
Connector 1 Orientation:
Straight
Minimum Bend Radius:
5xD (Fixed), 10xD (Flexible)
Fire Behaviour:
Halogen Free
Connector 1 Gender:
Male
Length:
300mm
Connector 2 Orientation:
Right Angle
Connector 2 Gender:
Female
Connector 2 Number of Contacts:
4
Conductor Material:
Bare Cu litz wires
Series:
SAC-4P-M12MS
Connector 1 Housing Gender:
Male
Connector 1 Number of Contacts:
4
Coding:
A
Sheath Colour:
Grey
Cross Sectional Area:
0.34 mm²
Connector 2:
M12
Connector 1:
M12
Insulation Material:
PP
1st Connector Orientation:
A
2nd Connector Mounting Type:
Free Hanging (In-Line)
HTSUS:
8544.42.9090
RoHS Status:
RoHS Compliant
Cable Material:
Ethylene Propylene Diene Monomer (EPDM), Polypropylene (PP)
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M12
2nd Connector Type:
Plug
Assembly Configuration:
Standard
2nd Connector Number of Positions:
4
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
0.98' (300.00mm)
1st Connector Gender:
Male Pins
standardLeadTime:
6 Weeks
1st Connector Type:
Receptacle, Right Angle
2nd Connector Shell Size - Insert:
M12
1st Connector Number of Positions:
8
Ingress Protection:
IP65/IP67/IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Color:
Gray
Series:
-
2nd Connector Orientation:
A
Cable Type:
Round
2nd Connector Number of Positions Loaded:
All
2nd Connector Gender:
Female Sockets
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
