ROHM 2SCR574DGTL NPN Transistor, 2 A, 80 V, 3+Tab-Pin DPAK

2SCR574DGTL ROHM NPN Transistor, 2 A, 80 V, 3+Tab-Pin DPAK
2SCR574DGTL
2SCR574DGTL
ROHM

Product Information

Minimum DC Current Gain:
120
Transistor Type:
NPN
Dimensions:
6.7 x 5.8 x 2.5mm
Mounting Type:
Surface Mount
Maximum Power Dissipation:
10 W
Maximum Collector Emitter Saturation Voltage:
300 mV
Maximum Collector Base Voltage:
80 V
Maximum Collector Emitter Voltage:
80 V
Maximum Operating Frequency:
100 MHz
Height:
2.5mm
Width:
5.8mm
Length:
6.7mm
Package Type:
DPAK (TO-252)
Number of Elements per Chip:
1
Maximum DC Collector Current:
2 A
Maximum Emitter Base Voltage:
6 V
Maximum Operating Temperature:
+150 °C
Pin Count:
3+Tab
Transistor Configuration:
Common Emitter
RoHs Compliant
Checking for live stock

This is NPN Transistor 2 A 80 V 3+Tab-Pin DPAK manufactured by ROHM. The manufacturer part number is 2SCR574DGTL. It features up to 120 of minimum DC current gain. The transistor is a npn type. The given dimensions of the product include 6.7 x 5.8 x 2.5mm. The product is available in surface mount configuration. Provides up to 10 w maximum power dissipation. The product has a maximum 300 mv collector emitter saturation voltage . Additionally, it has 80 v maximum collector base voltage. Whereas features a 80 v of collector emitter voltage (max). It carries 100 mhz of maximum operating frequency. In addition, the height is 2.5mm. Furthermore, the product is 5.8mm wide. Its accurate length is 6.7mm. The package is a sort of dpak (to-252). It consists of 1 elements per chip. Moreover, it has a maximum DC collector current of 2 a. It features a 6 v of maximum emitter base voltage. It has a maximum operating temperature of +150 °c. It contains 3+tab pins. The product offers common emitter transistor configuration.

pdf icon
2SCR574D, Power Transistor NPN (80V, 2A)(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
