This is Diodes Inc NPN High Voltage Bipolar Transistor 1.5 A 700 V 3-Pin TO-92 manufactured by DiodesZetex. The manufacturer part number is APT13003DZTR-G1. The given dimensions of the product include 4.7 x 3.7 x 4.7mm. The product has a maximum 0.4 v collector emitter saturation voltage . Furthermore, the product is 3.7mm wide. The product offers single transistor configuration. It carries 4 (min.) mhz of maximum operating frequency. The package is a sort of to-92. It consists of 1 elements per chip. It has a maximum operating temperature of +150 °c. The transistor is a npn type. Additionally, it has 10 v maximum collector base voltage. In addition, the product has a maximum 1.2 v base emitter saturation voltage . It features a 9 v of maximum emitter base voltage. Its accurate length is 4.7mm. Moreover, it has a maximum DC collector current of 1.5 a. It contains 3 pins. It features up to 5 of minimum DC current gain. The product is available in through hole configuration. Provides up to 1.1 w maximum power dissipation. Whereas features a 700 v of collector emitter voltage (max). In addition, the height is 4.7mm. Whereas, the minimum operating temperature of the product is -65 °c.
For more information please check the datasheets.
