Actual Diameter:
0.098" (2.50mm ID), 0.256" (6.50mm OD)
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Thread Size:
-
Operating Temperature:
-25°C ~ 65°C
Internal Switch(s):
Single Switch, Normally Closed
Shielding:
Unshielded
Voltage - Rated:
24VDC
Insulation Color:
-
Industry Recognized Mating Diameter:
2.50mm ID (0.098"), 5.50mm OD (0.217")
Includes:
-
edacadModel:
KLDX-SMT2-0202-BTR Models
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/9990106
Package:
Tape & Reel (TR)
Gender:
Male
Connector Type:
Jack
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Body Material:
-
Termination:
Solder
Current Rating (Amps):
3.5 A
Housing Material:
Liquid Crystal Polymer (LCP)
Body Color:
Black
Ingress Protection:
-
Features:
Board Guide, Solder Retention
Mounting Type:
Surface Mount, Right Angle
Mating Length/Depth:
-
Series:
KLDX-SMT2
Contact Material - Plating:
Silver
Contact Material:
Brass, Phosphor Bronze
Base Product Number:
KLDX-SMT
ECCN:
EAR99
