CUI Devices SJ1-3513-SMT-TR

Enrgtech Part No: ET18663573
|
Manufacturer Part No:
SJ1-3513-SMT-TR
|
Manufacturer: CUI Devices

Product Information

Mounting Type:

Surface Mount

Gender:

Female

Body Orientation:

Horizontal

Type:

Jack Connector

Size:

3.5 mm

Manufacturer Standard Lead Time:

11 Weeks

Detailed Description:

3.50mm (0.141", 1/8", Mini Plug) - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder

Actual Diameter:

0.142" (3.60mm)

Voltage - Rated:

12VDC

Housing Material:

Polyamide (PA6T), Nylon 6T

Operating Temperature:

-25°C ~ 85°C

Internal Switch(s):

Does Not Contain Switch

Checking for live stock

This is manufactured by CUI Devices. The manufacturer part number is SJ1-3513-SMT-TR. The product is available in surface mount configuration. In addition, female is the available "Gender" of the product. It has horizontal body orientation. It comes in jack connector configuration. The product is available in 3.5 mm size. It has typical 11 weeks of manufacturer standard lead time. It features 3.50mm (0.141", 1/8", mini plug) - headphone phone jack stereo (3 conductor, trs) connector solder. Its actual diameter is 0.142" (3.60mm). It also exhibits voltage rating of 12vdc. The product also features robust polyamide (pa6t), nylon 6t housing material. The product has -25°c ~ 85°c operating temperature range. Internal switch options: does not contain switch. Furthermore, the product is shielded with unshielded. The product consists of 3 conductors, 3 contacts positions or contacts. While the contact is gold. Features stereo (3 conductor, trs) signal lines. The product has 3.50mm (0.141", 1/8", mini plug) - headphone industrial recognised mating diameter. The cui devices's product offers user-desired applications. phone jack Connector type offer robust functionality. The product features solder termination style. Additionally, the product's output is 1a. The body has a classic black colour. The splendid features of the product include board guide. The product is available in surface mount, right angle configuration. The product has 0.551" (14.00mm) mating length or depth. The product sj1, is a highly preferred choice for users. In addition, cut tape (ct) is the available packaging type of the product. The product is made from sturdy brass; copper alloy materials.

Datasheet - SJ1-3513-SMT-TR(Technical Reference)

Plating 23/Jan/2019(PCN Design/Specification)

SJ1-351x-SMT(Datasheets)
