CUI Devices MJ-2523-SMT-TR

MJ-2523-SMT-TR CUI Devices
MJ-2523-SMT-TR
MJ-2523-SMT-TR
CUI Devices

Product Information

Mounting Type:
Surface Mount
Gender:
Female
Body Orientation:
Horizontal
Type:
Jack Connector
Size:
2.5 mm
Manufacturer Standard Lead Time:
11 Weeks
Detailed Description:
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone Phone Jack Mono Connector Solder
Actual Diameter:
0.102" (2.60mm)
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Housing Material:
Polyamide (PA6T), Nylon 6T
Operating Temperature:
-25°C ~ 85°C
Contact Material - Plating:
Silver
Shielding:
Unshielded
Voltage - Rated:
12VDC
Internal Switch(s):
Single Switch
Signal Lines:
Mono
Industry Recognized Mating Diameter:
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone
Manufacturer:
CUI Devices
Gender:
Female
Connector Type:
Phone Jack
Termination:
Solder
Current Rating (Amps):
1A
Body Color:
Black
Features:
Board Guide
Mounting Type:
Surface Mount, Right Angle
Packaging:
Cut Tape (CT)
Customer Reference:
Contact Material:
Brass; Copper Alloy
RoHs Compliant
Checking for live stock

This is manufactured by CUI Devices. The manufacturer part number is MJ-2523-SMT-TR. The product is available in surface mount configuration. In addition, female is the available "Gender" of the product. It has horizontal body orientation. It comes in jack connector configuration. The product is available in 2.5 mm size. It has typical 11 weeks of manufacturer standard lead time. It features 2.50mm (0.094", 3/32", sub mini, miniature) - headphone phone jack mono connector solder. Its actual diameter is 0.102" (2.60mm). The product consists of 2 conductors, 3 contacts positions or contacts. The product also features robust polyamide (pa6t), nylon 6t housing material. The product has -25°c ~ 85°c operating temperature range. While the contact is silver. Furthermore, the product is shielded with unshielded. It also exhibits voltage rating of 12vdc. Internal switch options: single switch. Features mono signal lines. The product has 2.50mm (0.094", 3/32", sub mini, miniature) - headphone industrial recognised mating diameter. The cui devices's product offers user-desired applications. phone jack Connector type offer robust functionality. The product features solder termination style. Additionally, the product's output is 1a. The body has a classic black colour. The splendid features of the product include board guide. The product is available in surface mount, right angle configuration. In addition, cut tape (ct) is the available packaging type of the product. The product is made from sturdy brass; copper alloy materials.
