Analog Devices AD7478ARTZ-500RL7, 8-bit Serial ADC, 6-Pin SOT-23

AD7478ARTZ-500RL7 Analog Devices , 8-bit Serial ADC, 6-Pin SOT-23
Analog Devices

Product Information

Number of ADCs:
1
Integral Nonlinearity Error:
±0.5LSB
Dimensions:
2.9 x 1.6 x 1.3mm
Mounting Type:
Surface Mount
Power Supply Type:
Single
Minimum Operating Temperature:
-40 °C
Digital Interface Type:
Serial (SPI/QSPI/Microwire)
Input Signal Type:
Single Ended
Typical Single Supply Voltage:
2.35 to 5.25 V
Package Type:
SOT-23
Architecture:
SAR
Input Type:
Voltage
Sampling Rate:
1Msps
Maximum Operating Temperature:
85 °C
Resolution:
8-bit
Pin Count:
6
RoHs Compliant
Checking for live stock

This is 8-bit Serial ADC 6-Pin SOT-23 manufactured by Analog Devices. The manufacturer part number is AD7478ARTZ-500RL7. It contains 1 ADCs . Its integral nonlinearity error is ±0.5lsb . The given dimensions of the product include 2.9 x 1.6 x 1.3mm. The product is available in surface mount configuration. It is a type of single power supply. Whereas, the minimum operating temperature of the product is -40 °c. Additionally, the product has a/an serial (spi/qspi/microwire) type digital interface . The input signal is a kind of single ended signal. It has a typical single supply voltage of 2.35 to 5.25 v. The package is a sort of sot-23. The product has been designed as sar. It carries voltage input type. It has about 1msps sampling rate . It has a maximum operating temperature of 85 °c. Features 8-bit resolution. It contains 6 pins.

pdf icon
AD7476/AD7477/AD7478, 1MSPS, 12-/10-/8-Bit ADCs in 6-Lead SOT-23(Technical Reference)
