Nichicon LNR1H473MSE

LNR1H473MSE Nichicon
LNR1H473MSE
LNR1H473MSE
ET10876317
ET10876317
Aluminum Electrolytic Capacitors
Aluminum Electrolytic Capacitors
Nichicon

Product Information

Dimensions:
51 x 90mm
Capacitance:
47000 µF
Tolerance:
±20%
Construction:
Metal Can
Maximum Operating Temperature:
+85°C
Terminal Type:
Screw Terminal
Tolerance Plus:
+20%
Leakage Current:
4.59 mA
Lead Pitch:
12.7mm
Package/Case:
JIS C 5101-1
Diameter:
51mm
Ripple Current:
8.6Arms
Mounting Type:
Chassis Mount
Series:
NR
Height:
90mm
Tolerance Minus:
-20%
Voltage:
50 V dc
Minimum Operating Temperature:
-40°C
Lifetime:
5000h
Technology:
Electrolytic
Ratings:
-
HTSUS:
8532.22.0055
RoHS Status:
ROHS3 Compliant
ESR (Equivalent Series Resistance):
-
Polarization:
Polar
Capacitance:
47000 µF
Operating Temperature:
-40°C ~ 85°C
Package / Case:
Radial, Can - Screw Terminals
Tolerance:
±20%
Voltage - Rated:
50 V
Height - Seated (Max):
3.661" (93.00mm)
Ripple Current @ High Frequency:
9.89 A @ 10 kHz
REACH Status:
REACH Affected
Ripple Current @ Low Frequency:
8.6 A @ 120 Hz
Applications:
General Purpose
Surface Mount Land Size:
-
Package:
Bulk
Size / Dimension:
2.008" Dia (51.00mm)
standardLeadTime:
51 Weeks
Moisture Sensitivity Level (MSL):
Not Applicable
Mounting Type:
Chassis Mount
Series:
LNR
Lifetime @ Temp.:
5000 Hrs @ 85°C
Lead Spacing:
0.500" (12.70mm)
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is manufactured by Nichicon. The manufacturer part number is LNR1H473MSE. The given dimensions of the product include 51 x 90mm. It provides a 47000 µf of capacitance value. It features ±20% of tolerance value. The product has been well-designed with metal can construction. It has a maximum operating temperature of +85°c. The terminal is a screw terminal type. It features a given value of +20% tolerance plus. It harbors 4.59 ma of leakage current. The lead features 12.7mm pitch. Concerning its package and casing, it is jis c 5101-1. Its diameter is 51mm. Furthermore, 8.6arms is the ripple current. The product is available in chassis mount configuration. The product nr, is a highly preferred choice for users. In addition, the height is 90mm. While it has tolerance minus of -20%. It carries a 50 v dc of voltage. Whereas, the minimum operating temperature of the product is -40°c. It provides a long-lasting service for a period of 5000h. This product use electrolytic technology. It is assigned with possible HTSUS value of 8532.22.0055. The product is rohs3 compliant. The product features a [Ploarization] polarity. The product has -40°c ~ 85°c operating temperature range. Moreover, the product comes in radial, can - screw terminals. It also exhibits voltage rating of 50 v. It has the maximum seated height of 3.661" (93.00mm). Additionally, it carries a ripple current and high frequency of 9.89 a @ 10 khz. In addition, it is reach affected. Its ripple current at low frequency is 8.6 a @ 120 hz. The product is widely employed in general purpose. It is shipped in bulk package . The product's diameters include 2.008" dia (51.00mm). It has a long 51 weeks standard lead time. Its typical moisture sensitivity level is not applicable. The product lnr, is a highly preferred choice for users. This product offers longer life span for 5000 hrs @ 85°c. It is assigned with 0.500" (12.70mm) of lead spacing. The product is designated with the ear99 code number.

pdf icon
Datasheet(Technical Reference)
pdf icon
LNR Series(Datasheets)
