Orion Fans OA119AP-22-1WB1855

OA119AP-22-1WB1855 Orion Fans
Orion Fans

Product Information

Material - Blade:
Metal
HTSUS:
8414.59.6590
RoHS Status:
ROHS3 Compliant
Width:
38.50mm
Power (Watts):
26.00W
Air Flow:
128.0 CFM (3.58m³/min)
Approval Agency:
cURus, TUV
Voltage Range:
200 ~ 240VAC
Noise:
48.0dB
Voltage - Rated:
230VAC
Lifetime @ Temp.:
50000 Hrs @ 55°C
REACH Status:
REACH Unaffected
Bearing Type:
Ball
Operating Temperature:
-22 ~ 176°F (-30 ~ 80°C)
RPM:
2950 RPM
Manufacturer:
Orion Fans
Static Pressure:
0.290 in H2O (72.2 Pa)
Size / Dimension:
Square - 127mm L x 127mm H
Termination:
2 Wire Leads
standardLeadTime:
19 Weeks
Current Rating (Amps):
-
Moisture Sensitivity Level (MSL):
Not Applicable
Ingress Protection:
IP55 - Dust Protected, Water Resistant
Features:
-
Weight:
1.4 lbs (635 g)
Series:
OA119
Material - Frame:
Aluminum
Packaging:
Box
Fan Type:
Tubeaxial
Base Product Number:
OA119
ECCN:
EAR99
Checking for live stock

This is manufactured by Orion Fans. The manufacturer part number is OA119AP-22-1WB1855. The blades are constructed from robust metal materials. It is assigned with possible HTSUS value of 8414.59.6590. The product is rohs3 compliant. Furthermore, the product is 38.50mm wide. The product features power and watts of 26.00w. It has a 128.0 cfm (3.58m³/min) air flow rate. It is approved by curus, tuv. While the voltage range is 200 ~ 240vac. It has noise values of 48.0db. It also exhibits voltage rating of 230vac. This product offers longer life span for 50000 hrs @ 55°c. In addition, it is reach unaffected. This has integrated with a ball, a bearing with long-lasting features. The product has -22 ~ 176°f (-30 ~ 80°c) operating temperature range. It provides maximum rpm up to 2950 rpm. The orion fans's product offers user-desired applications. The product has a 0.290 in h2o (72.2 pa) static pressure. The product's diameters include square - 127mm l x 127mm h. The product features 2 wire leads termination style. It has a long 19 weeks standard lead time. Its typical moisture sensitivity level is not applicable. It is IP rated with ip55 - dust protected, water resistant. The typical product's weight is 1.4 lbs (635 g). The product oa119, is a highly preferred choice for users. The frame of the product is made from highly durable aluminum materials. In addition, box is the available packaging type of the product. The latest designed fan is a type of tubeaxial offering unmatchable applications. Moreover, it corresponds to oa119, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
OA119 Series Panel Cutout(Datasheets)
pdf icon
Metal Fans Catalog(Datasheets)
pdf icon
OA119AP Series Datasheet(Datasheets)
pdf icon
AC Fans Accessories Matrix(Application Notes)
pdf icon
AC,DC Part Number Guide(Application Notes)
pdf icon
All Metal Fans Sales Sheet(Application Notes)
pdf icon
Selector Guide(Design Resources)
pdf icon
Technical Terms(Design Resources)
