Maximum Temperature:
+70°C
Minimum Temperature:
-25°C
Application:
Blood Glucose Meter, Blood Pressure Meter, Inhaler, Nebuliser, Portable Medical Device, Sleep Apnea Device
MTBF:
400kh
Protection Features:
Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switched Mode Power Supply
Holdup Time:
16ms
Load Regulation:
±5%
Standards Met:
ANSI/AAMI ES60601-1/60601-1-11, CB, CE, CULus Recognised, EISA 2007/DOE, EN 55011 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EU ErP, FCC PART 15/CISPR22 Class B, MIL-HDBK-217F, TUV 60601-1-11, TUV Rheinland EN 60601-1, TUV Rheinland IEC 60601-1
Maximum Input Current:
1 A @ 115 V ac, 600 mA @ 230 V ac
Input Frequency Range:
47 → 63Hz
Input Voltage:
80 → 264V ac
Depth:
56.2mm
Number of Outputs:
1
Line Regulation:
±1%
Ripple And Noise:
100mV Pk-Pk
Length:
39.1mm
Special Features:
Fully Enclosed Plastic Case, Interchangeable AC Plug, Low Leakage Current, No Load Power Consumption
Medical Approved:
Yes
Power Signal Conversion Type:
AC-DC
Weight:
200g
Output Current:
0 → 4A
Width:
75.5mm
Series:
GEM40I
Plug Type:
Australia, European Plug, UK, US
Output Voltage:
9 V dc
Power Rating:
36W
Cable Length:
1m
